产品介绍
技术参数 标准版 产品型号 | 电压 | 电流 | 功率 | 分辨率（电压/电流） | 精度（电压/电流） | 尺寸 | C3000N-5K-0100-0200 | 100V | 200A | 5kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000N-10K-0100-0400 | 100V | 400A | 10kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000N-15K-0100-0600 | 100V | 600A | 15kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000N-7K5-0750-0060 | 750V | 60A | 7.5kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000N-15K-0750-0120 | 750V | 120A | 15kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000N-30K-0750-0180 | 750V | 180A | 30kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000N-15K-1500-0060 | 1500V | 60A | 15kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000N-21K-2000-0060 | 2000V | 60A | 21kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000N-30K-2000-0060 | 2000V | 60A | 30kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U |
专业版 Pro 产品型号 | 电压 | 电流 | 功率 | 分辨率（电压/电流） | 精度（电压/电流） | 尺寸 | C3000P-5K-0100-0200 | 100V | 200A | 5kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000P-10K-0100-0400 | 100V | 400A | 10kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000P-15K-0100-0600 | 100V | 600A | 15kW | 0.01V/0.01A | ≤0.02%F.S/≤0.1% F.S | 3U | C3000P-7K5-0750-0060 | 750V | 60A | 7.5kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000P-15K-0750-0120 | 750V | 120A | 15kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000P-30K-0750-0180 | 750V | 180A | 30kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000P-15K-1500-0060 | 1500V | 60A | 15kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000P-21K-2000-0060 | 2000V | 60A | 21kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U | C3000P-30K-2000-0060 | 2000V | 60A | 30kW | 0.01V/0.01A | ≤0.05%F.S/≤0.1% F.S | 3U |
| |
